Uitvoering:
- Integreerbare afzuigkap
Design:
- Kleur: Roestvrij staal
Gebruiksmogelijkheden:
- Soort luchtafvoer: Converteerbaar
Bedieningsgemak:
- Elektronische besturing
- Tiptoetsen
- Vermogensstanden (exclusief Intensiefstand): 3
- Intensiefstand
- Programmeerbare in-/ uitschakelautomaat
Efficiëntie en duurzaamheid:
- Jaarlijks energieverbruik in kWh/jaar: 101,3
Filtersysteem:
- Roestvrijstalen vaatwasserbestendig vetfilter: 2
Verlichting:
- Led
- Aantal lampen x Watt: 2 x 1,1 W
- Lichtsterkte in Lx: 210
Ventilator:
- Tweevoudig luchtaanzuigsysteem
- Wisselstroommotor (AC-motor)
Vermogen bij max. diameter afvoer voor luchtafvoer (niet bij externe variant):
- Afzuigcapaciteit luchtafvoer bij stand 1 (m³/h): 320
- Afzuigcapaciteit luchtafvoer bij stand 2 (m³/h): 480
- Afzuigcapaciteit luchtafvoer bij stand 3 (m³/h): 610
- Afzuigcapaciteit circulatie bij Intensiefstand (m³/h): 690
- Geluidsniveau stand 1 (dB(A) re1pW): 52
- Geluidsniveau stand 2 (dB(A) re1pW): 62
- Geluidsniveau stand 3 (dB(A) re1pW): 67
- Geluidsniveau Intensiefstand (dB(A) re1pW): 69
- Afzuigcapaciteit luchtafvoer bij stand 1 (m³/h): 225
- Afzuigcapaciteit luchtafvoer bij stand 2 (m³/h): 290
- Afzuigcapaciteit luchtafvoer bij stand 3 (m³/h): 315
- Afzuigcapaciteit luchtafvoer bij Intensiefstand (m³/h): 330
- Geluidsniveau stand 1 (dB(A) re1pW): 68
- Geluidsniveau stand 2 (dB(A) re1pW): 73
- Geluidsniveau stand 3 (dB(A) re1pW): 75
- Geluidsniveau Intensiefstand (dB(A) re1pW): 76
Technische gegevens:
- Breedte van afzuigkap in mm: 599
- Hoogte van afzuigkap in mm: 450
- Diepte van afzuigkap in mm: 275
- Minimale afstand boven elektrische kookplaten in mm: 650
- Minimale afstand boven gaskookplaten (max 12,6 gezamenlijk vermogen, gasbrander ? 4,5 kW) in mm: 650
- Nettogewicht in kg: 11,8
- Lengte aansluitkabel in meters: 1,2
- Geaarde stekker
- Totale aansluitwaarde in kW: 0,25
- Spanning in Volt: 230
- Zekering in A: 10
- Frequentie in Hz: 50
- Aansluiting op aantal fasen: 1
Montage-instructies:
- Luchtafvoeraansluiting bovenzijde
- Diameter ventilatierooster in mm: 150
- Montagesjabloon
Meegeleverde accessoires:
- Terugslagklep
- Reductie van Ø 150 naar 120 mm:
